Cord Winding Crack Tester
Model: SZ-6808
If the cross-sectional area of conductor is less than 100mm2 .Then specimen must be put into testing chamber for freezing for one hour, after that immediately rolls specimen around the specified rod in a uniform speed. Otherwise, for the cross-sectional area over 100mm2, roll the specimen beforehand and put into chamber for freezing one hour. Afterwards, immediately roll specimen around the rod in reverse direction. Finally, take out of specimen for checking whether its surface has crack or fissure or not.

Test Standard

  • GB/T 2951.14-2008 idt IEC 60811-1-4:1985 电缆和光缆绝缘和护套材料通用试验方法第14部分:通用试验方法 低温试验
  • UL 62-2010 软线和电缆
  • JIS C 3005-2000 橡胶或塑料绝缘电线和电缆的试验方法

Specifications

Model

SZ-6808

Interior Dimensions

W600×D500×H600mm

Temp. Range

Room temp.-70

Temp. Accuracy

±0.5

Temp. Uniformity

≤±2

Temp. Control

LCD touch programmable temperature controller

Cooling Way

Air-cooled compressor refrigeration

Dimension

W1600×D750×H950mm

Weight

260kg

Power

1 AC220V 50HZ
